5IK 90mm 90W

Speed Control Motor

Motor Type: 5IK

Power: 90W

Voltage: 110-380V

Gearbox Ratio: 3-180K

Motor Parameter Table

Model ·Type Lead Wire Type	Output power W	Voltage V	Frequency Hz	Speed Control Range r/min	Allowance Torque		Starting Torque mN.m	Current A	Capacitor μF
Pinion Shaft					1200r/min mN.m	90r/min mN.m
5IK90RGU-AF	90	1ph 100	50	90~1400	710	230	405	1.55	25
			60	90~1700		260		1.85
5IK90RGU-EF	90	1ph 110	60	90~1700	710	260	410	1.40	20
		1ph 120						1.45
5IK90RGU-CF	90	1ph 220	50	90~1400	710	230	410	0.72	5.0
		1ph 230						0.70
5IK90RGU-HF	90	1ph 220	60	90~1700	710	260	410	0.71	5.0
		1ph 230						0.75

Allowance Torque

Type Motor/Gearhead		Gear Ratio		3	3.6	5	6	7.5	9	10	12.5	15	18	20	25	30	36	50	60	75	90	100	120	150	180
		Speed r/min	50Hz	500	417	300	250	200	166	150	120	100	83	75	60	50	42	30	25	20	16	15	12	10	8
		Speed r/min	60Hz	600	500	360	300	240	200	180	144	120	100	90	72	60	50	36	30	24	20	18	15	12	10
5IK9ORGU-AF□ 5IK90RGUEF□ 5IK9ORGU-CF□ 5IK90RGU-HF□	5GU□RC 5GU□RT	Allowance Torque	50Hz	1.13	1.35	1.88	2.26	3.55	3.76	4.18	5.92	7.10	7.52	8.35	11.8	14.2	15.3	20.0	20.0	20.0	20.0	20.0	20.0	20.0	20.0
			50Hz	11.1	13.3	18.4	22.1	36.2	36.8	40.9	60.4	72.5	73.7	81.9	121	145	157	200	200	200	200	200	200	200	200
			60Hz	0.94	1.13	1.57	1.88	2.86	3.13	3.48	4.77	5.73	6.27	6.96	9.54	11.5	12.4	17.2	20.0	20.0	20.0	20.0	20.0	20.0	20.0
			60Hz	9.21	11.1	15.4	18.4	29.2	30.7	34.1	48.7	58.4	61.4	68.2	97.4	117	126	175	200	200	200	200	200	200	200

Lead Wiring Type

Description

The integrated drive speed control motor features a core advantage in the seamless integration of drive control and precise speed regulation. This model has a rated power of 90W and supports a wide voltage input range of 110V–380V, making it compatible with various regional power standards and ensuring flexible deployment of equipment on a global scale. The motor adopts a compact structural design, with the drive unit highly integrated into the motor body, reducing the need for external wiring and additional control modules, simplifying installation while maintaining excellent heat dissipation and mechanical strength. This ensures reliable operation under continuous use and high-frequency speed control conditions.
Through the integrated drive system, the motor achieves rapid response and precise speed adjustment, maintaining stable output even under frequent start-stop operations or varying load conditions. The optimized stator-rotor structure and control algorithms provide smooth torque output at low, medium, and high load conditions, effectively minimizing vibration and mechanical impact on the equipment structure. Its high-efficiency speed regulation makes it particularly suitable for conveyor systems, packaging machinery, sorting equipment, and small lifting devices, enabling precise cycle control on production lines and continuous operational performance.
