5IK 90mm 120W

Speed Control Motor

Motor Type: 5IK

Power: 120W

Voltage: 110-380V

Gearbox Ratio: 3-180K

Motor Parameter Table

Model ·Type Lead Wire Type	Output power W	Voltage V	Frequency Hz	Speed Control Range r/min	Allowance Torque		Starting Torque mN.m	Current A	Capacitor μF
Pinion Shaft					1200r/min mN.m	90r/min mN.m
5IK120RGU-AF	120	1ph 100	50	90~1400	750	330	530	2.10	30
			60	90~1700				2.50
5IK120RGU-EF	120	1ph 110	60	90~1700	750	360	530	1.65	25
		1ph 120						1.80
5IK120RGU-CF	120	1ph 220	50	90~1400	750	330	530	1.00	7.0
		1ph 230						0.95
5IK120RGU-HF	120	1ph 220	60	90~1700	750	360	530	1.00	7.0
		1ph 230						0.95

Allowance Torque

Type Motor/Gearhead		Gear Ratio		3	3.6	5	6	7.5	9	10	12.5	15	18	20	25	30	36	50	60	75	90	100	120	150	180
		Speed r/min	50Hz	500	417	300	250	200	166	150	120	100	83	75	60	50	42	30	25	20	16	15	12	10	8
		Speed r/min	60Hz	600	500	360	300	240	200	180	144	120	100	90	72	60	50	36	30	24	20	18	15	12	10
5IK120RGUAF□ 5IK120RGUEF□ 5IK120RGU-CF□ 5IK120RGUHF□	5GU□RC 5GU□RT	Allowance Torque	50Hz-	1.50	1.80	2.51	3.01	4.73	5.01	5.57	7.89	9.47	10.0	11.14	15.8	18.9	20.0	20.0	20.0	20.0	20.0	20.0	20.0	20.0	20.0
			50Hz-	14.7	17.7	24.6	29.5	48.3	49.1	54.6	80.5	96.6	98.3	109	161	193	200	200	200	200	200	200	200	200	200
			60Hz	1.25	1.50	2.09	2.51	3.82	4.18	4.64	6.36	7.64	8.35	9.28	12.7	15.3	16.5	20.0	20.0	20.0	20.0	20.0	20.0	20.0	20.0
			60Hz	12.3	14.7	20.5	24.6	39.0	40.9	45.5	64.9	77.9	81.9	91.0	130	156	168	200	200	200	200	200	200	200	200

Lead Wiring Type

Description

The high protection level speed-controlled motor is a high-performance power unit developed for industrial automation and medium-duty mechanical transmission systems, specifically designed for harsh operating conditions and complex environments. This model has a rated power of 120W and supports a wide voltage input of 110V–380V, making it compatible with power standards in various regions and facilitating flexible deployment and application across different markets. The motor features a sealed protective design with high dustproof and waterproof ratings, effectively preventing dust, liquids, and contaminants from entering the motor, ensuring long-term operational reliability. Its compact structural design allows for easy installation in space-constrained equipment while maintaining excellent heat dissipation and mechanical strength, providing stable power for continuous operation under high-load conditions.
In terms of performance, the motor utilizes an optimized stator-rotor structure and winding design to deliver smooth and adjustable speed output across low to high-speed ranges. It maintains stable torque even under load fluctuations or frequent start-stop operations, reducing vibration and mechanical impact on connected equipment. The combination of high protection and stable speed control makes this motor suitable for a variety of industrial applications, including conveyor systems, packaging machinery, sorting equipment, and small lifting devices, particularly in environments with high dust levels, humidity, or exposure to liquid splashes.
For transmission matching, the motor can be paired with gearboxes offering a 3–180K reduction ratio, allowing flexible adjustment of output speed and torque according to specific load requirements. By optimizing the combination of gearbox and motor output, this high protection level speed-controlled motor achieves high torque and reliable, controllable power within a compact form factor, providing safe, stable, and efficient power support for industrial automation systems.
