5IK 90mm 60W

Induction Motor

Motor Type: 5IK

Power: 60W

Voltage: 110-380V

Gearbox Ratio: 3-180K

Motor Parameter Table

Model ·Type Upper:Pinion Shaft Below:Round Shaft		Output power W	Voltage V	Frequency Hz	Current A	Starting Torque mN.m	Rated Torque mN.m	Rated Speed r/min	Capacitor μF
Lead Wire Type Dimensions①	Terminal Box Type Dimensions②
5IK60GU-AF	5IK60GU-AFT	60	1ph 100	50	1.00	320	470	1250	20
				60	1.10		380	1550
5IK60GU-EF	5IK60GU-EFT	60	1ph 110	60	0.80	300	380	1550	12
			1ph 120		0.85
5IK60GU-CF	5IK60GU-CFT	60	1ph 220	50	0.50	340	470	1250	4.0
			1ph 230		0.55
5IK60GU-HF	5IK60GU-HFT	60	1ph 220	60	0.50	340	380	1550	4.0
			1ph 230		0.55
5IK60GU-SF	5IK60GU-SFT	60	3ph 220	50	0.45	1000	470	1250	-
				60	0.40	800	380	1550
5IK60GU-S3F	5IK60GU-S3FT	60	3ph 380	50	0.26	1000	470	1250	-
				60	0.23	800	380	1550

Allowance Torque

Type Motor/Gearhead		Gear Ratio		3	3.6	5	6	7.5	9	10	12.5	15	18	20	25	30	36	50	60	75	90	100	120	150	180
		Speed r/min	50Hz	500	417	300	250	200	166	150	120	100	83	75	60	50	42	30	25	20	16	15	12	10	8
		Speed r/min	60Hz	600	500	360	300	240	200	180	144	120	100	90	72	60	50	36	30	24	20	18	15	12	10
5IK60GU-AF□ 5IK60GU-F□ 5IK60GU-CF□ 5IK60GU-HF□ 5IK60GU-SF□ 5IK60GU-S3F□	5GU□RC 5GU□RT	Allowance Torque	50Hz	0.75	0.90	1.25	1.50	2.37	2.76	3.06	3.95	4.73	5.51	6.13	7.89	9.47	10.2	14.2	17.0	20.0	20.0	20.0	20.0	20.0	20.0
			50Hz	7.37	8.84	12.3	14.7	24.2	27.0	30.0	40.3	48.3	54.0	60.0	80.5	96.6	104	145	174	200	200	200	200	200	200
			60Hz	0.63	0.75	1.04	1.25	1.91	2.30	2.55	3.18	3.82	4.59	5.11	6.36	7.64	8.25	11.5	13.7	17.2	20.0	20.0	20.0	20.0	20.0
			60Hz	6.14	7.37	10.2	12.3	19.5	22.5	25.0	32.5	39.0	45.0	50.0	64.9	77.9	84.1	117	140	175	200	200	200	200	200

Lead Wiring Type

Description

The compact drive induction motor is engineered for industrial automation applications that demand reliable torque output within a limited installation space. This model features a rated power of 60W and supports a wide voltage range of 110V–380V, making it compatible with multiple regional power standards and versatile for integration across various automated systems. Its compact structure allows seamless installation in space-constrained environments without compromising performance or mechanical stability.
Designed with an optimized electromagnetic structure, the motor delivers consistent torque output and smooth operation under continuous load conditions. Its construction ensures minimal vibration and noise, contributing to improved system reliability and longer operational life. The motor is particularly suitable for driving conveyor units, small lifting mechanisms, packaging machinery, and other auxiliary industrial equipment where stable performance and compact form factor are critical.
This motor is compatible with gearboxes offering reduction ratios from 3 to 180K, providing flexible options for adjusting output speed and torque to match specific application requirements. When paired with the appropriate gearbox, the compact drive motor achieves high torque output and efficient power transmission even in limited spaces, ensuring precise and responsive motion control. Its design emphasizes both structural rigidity and thermal stability, allowing for continuous operation in demanding industrial environments.
