100W

Three Phase Small AC Gear Motor

Motor Type: Horizontal & Vertical

Power:1/8HP

Voltage:1-Phase&3-Phase 220-380V

Gearbox Ratio:3-1800

Motor Parameter Table

Power	Box Number	Ratio	A	D	E	F	G	H	J	K	L	M	X	Y	Z	S	P	Q	W	T	Weight
100W 1/8HP	1#	3-50 Standard type	254	40(50)	110(140)	135(120)	65(120)	9	16	50(39.5)	10(12)	130.5	143(/)	88.5(2)	100	18	30	27	5	20.2	5.7
	1#	60-200 Light duty type	254	40(50)	110(140)	135(120)	65(120)	9	16	50(39.5)	10(12)	130.5	143(/)	88.5(2)	100	18	30	27	5	20.2	5.7
	2#	60-200 Standard type	281	65(148)	130(185)	158(175)	90(165)	12	17.5	60(48)	13(12)	130.5	161(/)	97.5(3)	100	22	40	35	7	25	7.30
	2#	250-1800 Light duty type (1#+2#)	341	65(148)	130(185)	158(175)	90(165)	12	33.5	60(48)	13(12)	130.5	161(/)	97.5(3)	100	22	40	35	7	25	12.0
	3#	250-1800 Standard type (1#+3#)	376	90(170)	140(220)	178(205)	120(195)	12	39	68(58)	17(13)	130.5	184(/)	116(3)	100	28	45	40	7	31.1	14.5
	3#	250-1800 Standard type (1#+3#)	/	/	/	/	/	/	/	/	/	/	/	/	/	/	/	/	/	/	/

Allowance Torque

Power

Box

Number

Type

Speed frequency ratio

100

120

140

160

180

200

100W

1/8HP

Standard type

50Hz

0.20

0.30

0.60

0.80

1.10

1.40

1.70

2.30

2.50

2.80

60Hz

0.16

0.26

0.52

0.76

1.0

1.20

1.50

1.90

2.20

2.30

Light duty type

50Hz

3.40

60Hz

3.40

Standard type

50Hz

3.40

3.90

4.50

5.10

5.60

6.80

7.90

9.00

10.1

11.3

60Hz

2.80

3.30

3.70

4.20

4.60

5.60

6.50

7.40

8.40

9.30

Light duty type

50Hz

60Hz

Power	Box Number	Type	Speed frequency ratio	250	300	350	400	450	500	600	700	800	900	1000	1100	1200	1300	1400	1500	1600	1700	1800
100W 1 /8HP	1#+2#	Light duty type	50Hz	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6
	1#+2#	Light duty type	60Hz	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6	11.6
	1#+3#	Standard type	50Hz	11.2	11.2	11.2	11.2	11.2	11.2	22.9	22.9	22.9	22.9	22.9	22.9	22.9	22.9	22.9	22.9	22.9	22.9	22.9
	1#+3#	Standard type	60Hz	11.2	11.2	11.2	11.2	11.2	11.2	22.9	22.9	22.9	22.9	22.9	22.9	22.9	22.9	22.9	22.9	22.9	22.9	22.9
