Motor Type: Brush Machine
Voltage: 24V DC
Power: 310W
|
Type |
ZDSJ-24310GU-18S-N |
Protection grade |
IP00 |
|
Rated voltage |
24VDC |
Ambient temperature |
-10℃~+40℃ |
|
Rated power |
310W |
Noise |
<60dB(L=100cm) |
|
Rated current |
16A |
Ratio |
10:1 |
|
Rated speed |
1800rpm±10% |
Rated output speed |
14.8N.m |
|
Rated torque |
1.64N.m |
||
|
Noload current |
≤4A |
Efficiency |
90% |
|
Noload speed |
2300rpm±10% |
Wire diagram |
![]() |
|
Work duty |
S2-30min |
||
|
Insulation resistance |
>20MΩ |
||
|
Brush life |
1000h |
||
|
Electrical strength |
660V/S |
||
|
Insulation class |
B |
