5RK 90mm 40W

AC Brake Motor

Motor Type: 5RK

Power: 40W

Voltage: 110-380V

Gearbox Ratio: 3-200K

Motor Parameter Table

Model ·Type Lead Wire Type		Rating	Output Power W	Voltage V	Frequeny Hz	Current A	Starting Torque mN.m	Rated Torque mN.m	Rated Speed r/min	Capacitor μF
Pinion Shaft	Round Shaft
5RK40GN-AM	5RK40A-AM	30min	40	1ph 100	50	0.78	300	315	1250	15.0
					60	1.05		260	1550
5RK40GN-EM	5RK40A-EM	30min	40	1ph 110	60	0.79	260	260	1550	12.0
				1ph 120		0.80
5RK40GN-CM	5RK40A-CM	30min	40	1ph 220	50	0.45	270	315	1250	3.00
				1ph 230
5RK40GN-HM	5RK40A-HM	30min	40	1ph 220	60	0.45	270	260	1550	3.00
				1ph 230
5RK40GN-SM	5RK40A-SM	30min	40	3ph 220	50	0.30	800	315	1250	0.30
					60	0.25	660	250	1600	0.25
5RK40GN-S3M	5RK40A-S3M	30min	40	3ph 380	50	0.17	800	315	1250	0.30
					60	0.14	660	250	1600	0.25

Allowance Torque

Type Motor/Gearhead	Gear Ratio		3	3.6	5	6	7.5	9	10	12.5	15	18	20	25	30	36	40	50	60	75	90	100	120	150	180	200
	Speed r/min	50Hz	500	417	300	250	200	166	150	120	100	83	75	60	50	41	37	30	25	20	16	15	12.5	10	8.3	7.5
	Speed r/min	60Hz	600	500	360	300	240	200	180	144	120	100	90	72	60	50	45	36	30	24	20	18	15	12	10	9
5RK40GN-AM 5RK40GN-EM 5RK40GN-CM 5RK40GN-HM 5RK40GN-SM 5RK40GN-S3M	5GN□K	50Hz	0.77	0.92	1.30	1.50	1.90	2.30	2.38	3.20	3.80	4.60	4.88	5.70	6.90	8.30	8.57	10.0	10.0	10.0	10.0	10.0	10.0	10.0	10.0	10.0
		50Hz	7.85	9.38	13.2	15.3	19.4	23.4	24.3	32.6	38.7	46.9	49.8	58.1	70.4	84.7	87.4	100	100	100	100	100	100	100	100	100
		60Hz	0.63	0.76	1.10	1.30	1.60	1.90	2.00	2.60	3.20	3.80	4.07	4.70	5.70	6.80	7.19	8.60	10.0	10.0	10.0	10.0	10.0	10.0	10.0	10.0
		60Hz	6.42	7.75	11.2	13.2	16.3	19.3	20.4	16.5	32.6	38.7	41.5	47.9	58.1	69.3	73.4	87.7	100	100	100	100	100	100	100	100

Lead Wiring Type

Description

The heavy-duty AC braking motor is an integrated power and braking product designed for high-load, continuous operation conditions. It is suitable for industrial equipment requiring high output power, operational stability, and reliable braking. This model uses a 5RK motor type, featuring a reinforced design in terms of electromagnetic structure and mechanical strength. With a rated power of 40W, it can maintain stable output under heavy load conditions, providing sufficient driving margin for the equipment and reducing the impact of load fluctuations on system operation.
The motor supports a wide voltage input range of 110V–380V, allowing for flexible matching to power supply standards in different regions and industries, facilitating deployment and use in various scenarios. The motor integrates a highly reliable braking mechanism, which can quickly respond and output a stable braking torque in the event of power failure or shutdown. This effectively locks the load position, preventing slippage of heavy-duty systems due to inertia or external forces, thereby improving the safety and controllability of the entire machine.
This product can be paired with a reduction ratio range of 3–200K, enabling flexible switching from medium-speed operation to low-speed, high-torque output according to actual application needs. Through reasonable matching with the reduction mechanism, the motor can convert higher power into greater effective torque, meeting the requirements of heavy-duty conveying, lifting, pushing, and pulling applications. Simultaneously, the reduction system and braking unit work together to reduce mechanical shock during starting and braking, improving the overall smoothness of system operation.
