2RK 60mm 6W

AC Brake Motor

Motor Type: 2RK

Power: 6W

Voltage: 110-380V

Gearbox Ratio: 3-200K

Motor Parameter Table

Model ·Type Lead Wire Type		Rating	Output Power W	Voltage V	Frequeny Hz	Current A	Starting Torque mN.m	Rated Torque mN.m	Rated Speed r/min	Capacitor μF
Pinion Shaft	Round Shaft
2RK6GN-AM	2RK6A-AM	30min	6	1ph 100	50	0.265	60	48	1200	4.0
					60	0.232	55	40	1450
2RK6GN-EM	2RK6A-EM	30min	6	1ph 110	60	0.185	45	40	1450	2.5
				1ph 120		0.200
2RK6GN-CM	2RK6A-CM	30min	6	1ph 220	50	0.145	55	48	1200	1.0
				1ph 230		0.150
2RK6GN-HM	2RK6A-HM	30min	6	1ph 220	60	0.145	60	40	1450	1.0
				1ph 230		0.150
2RK6GN-SM	2RK6A-SM	30min	6	3ph 220	50	0.076	85	48	1200	-
					60	0.065	70	40	1450
2RK6GN-S3M	2RK6A-S3M	30min	6	3ph 380	50	0.044	85	48	1200	-
					60	0.038	70	40	1450

Allowance Torque

Type Motor/Gearhead	Gear Ratio		3	3.6	5	6	7.5	9	10	12.5	15	18	20	25	30	36	40	50	60	75	90	100	120	150	180	200
	Speed r/min	50Hz	500	417	300	250	200	166	150	120	100	83	75	60	50	41	37	30	25	20	16	15	12.5	10	8.3	7.5
	Speed r/min	60Hz	600	500	360	300	240	200	180	144	120	100	90	72	60	50	45	36	30	24	20	18	15	12	10	9
2RK6GN-AM 2RK6GN-EM 2RK6GN-CM 2RK6GN-HM 2RK6GN-SM 2RK6GN-S3M	2GN□K	50Hz	0.12	0.14	0.19	0.23	0.29	0.35	0.39	0.49	0.58	0.70	0.75	0.88	1.10	1.30	1.39	1.60	1.90	2.40	2.90	3.00	3.00	3.00	3.00	3.00
		50Hz	1.22	1.43	1.94	2.35	2.96	3.57	3.98	5.00	5.92	7.14	7.65	8.98	11.2	13.3	14.2	16.3	19.4	24.5	29.6	30.0	30.0	30.0	30.0	30.0
		60Hz	0.10	0.12	0.16	0.19	0.24	0.29	0.32	0.41	0.49	0.58	0.62	0.73	0.88	1.10	1.15	1.30	1.60	2.00	2.40	2.60	3.00	3.00	3.00	3.00
		60Hz	1.02	1.22	1.63	1.94	2.45	2.96	3.26	4.18	5.00	5.92	6.32	7.45	8.98	11.2	11.7	13.3	16.3	20.4	24.5	26.5	30.0	30.0	30.0	30.0

Lead Wiring Type

Description

The general-purpose AC brake motor is a highly reliable integrated drive and braking product designed for basic industrial automation applications. It is suitable for equipment systems with specific requirements for positioning stability, operational safety, and structural versatility. This model utilizes a 2RK motor structure, achieving stable output in a compact size, with a rated power of 6W. It is particularly suitable for light loads, high-frequency start-stop applications, and automation equipment with limited space.
This general-purpose AC brake motor supports a wide voltage range of 110V–380V, meeting the power supply standards of different countries and regions, while reducing the complexity of system selection and inventory management. It can be quickly integrated into both independent equipment and complete automation systems, reducing electrical modification costs. The motor has a built-in braking unit, which can quickly generate a stable braking torque when power is off or the motor stops, effectively preventing load slippage and improving the safety and controllability of equipment operation.
This product can be matched with a reduction ratio range of 3–200K, flexibly covering various operating conditions from low-speed high torque to relatively high-speed operation. By rationally selecting the reduction ratio, more precise speed control and higher output stability can be achieved, meeting the requirements of conveying mechanisms, positioning mechanisms, small lifting units, and automated execution components. The close cooperation between the reduction mechanism and the motor helps reduce operating noise and transmission shock, improving the overall smoothness of the system.
